MA-8120
Mains Supply: 220 - 240V/50Hz
Power consumption: 240W
Power Output: 120W
Dimensions(WHD): 440×98×330mm
Net weight: 12kg
Product Details
Three microphone inputs, three auxiliary inputs, and one auxiliary output for link
•Transformer isolated 100/70V and 4Ω speaker outputs
•Muting function
•Individual volume control
•Low and high tone control
•A five-element LED level meter is provided for quick and easy visual monitoring of the sound level
•Short-circuit protection and alarm
•Chime out prior to other inputs
•Individual distributor for 6 channels
•24V DC pack-up sources
•Mains supply range: 220 to 240V at 50Hz
•Power consumption: 240W
•Power output: 120W
•Output regulation: <3dB
•Frequency response: 100 to 16,000Hz
•Distortion (THD): less than 0.3% at 1kHz and 1/3 rated power
•Speaker outputs: 4 to 16Ω and 70/100V
•Aux output: 600Ω and 1V (odBV)
▪Mic 1, 2, 3: 600Ω and 6mΩ unbalanced
▪Aux 1, 2, 3: 10kΩ and 250mΩ unbalanced
◦Inputs:
▪Mic 1, 2, 3: ≥66dB
▪Aux 1, 2: ≥70dB
◦S/N ratios:
▪Bass: ±10dB at 100Hz
▪Treble: ±10dB at 10kHz
◦Tone controls:
•Protection: AC fuse, DC voltage, overload and short circuit
•Backup: 24V DC
•Muting function: 0 to 30dB
•Dimension (W x H x D): 440 x 92 x 330mm
•
Net weight: 12kg
